General Information |
Manufacturer Name: | Goal Zero |
Chainable: | No |
Dimensions: | 15.3 x 10.1 x 17 in (38.9 x 25.7 x 43.2 cm) |
Weight: | 106 lbs (48.1 kg) |
Operating usage temp: | 32-104 F (0-40 C) |
Warranty: | 2 Year Warranty |
Battery | Cell Type: | Li-ion NMC |
Pack Capacity: | 6071Wh (10.9V, 556Ah) |
Management System: | MPPT charge controller, low battery protection |
Lifecycles: | 500 Cycles to 80% capacity (Approx. 2000 cycles with depreciation)(Discharge rate: 1C, full charge/discharge, Temp 25C) |
Shelf-life: | Keep plugged in, or charge every 3-6 months |
Ports | USB-A port (output): | 5V, up to 2.4A (12W max), regulated |
USB-C port (output): | 5 - 12V, up to 3.0A (18W max), regulated |
USB-C PD port (input/output): | 5 - 20V, up to 3.0A (60W max), regulated |
6mm Port (output): | 12V, up to 10A (120W max), regulated |
12V HPP (output): | 12V, up to 30A (360W max), regulated |
12V Car Port (output): | 12V, up to 13A (160W max), regulated |
AC Inverter (output, Pure sine wave): | 120V AC Inverter: 120VAC 60Hz, 16.5A (2000W, 3500W surge) |
Charging Port (input, 8mm): | 14-50V, up to 10A (150W max) |
HPP charging port (input): | 14-50V, up to 50A (600W max) |
Charge Times | AC Wall Charger: | 600W: 12 Hours |
400 Watts of Solar: | 18-36 Hours |
What can the Yeti 6000X Power? | Smart Phone (12 Wh): | 451 Charges |
Tablet (30 Wh): | 201 Charges |
Laptop (50 Wh): | 120 Charges |
POV Camera (5 Wh): | 1202 Charges |
DSLR Camera (18 Wh): | 334 Charges |
Head Lamp (5 Wh): | 1202 Charges |
Light-a-Life 350 (4.5 Wh): | 1336 Hours |
Light Bulb (11 Wh): | 547 Hours |
CPAP (65 Wh): | 93 Hours |
TV (42" LED) (100 Wh): | 60 Hours |
Pellet Grill (60 Wh): | 51 Hours |
Microwave (1000 Wh): | 6 Hours |
Portable Fridge (25 Wh): | 241 Hours |
Mini Fridge(35 Wh): | 172 Hours |
Full Size Refrigerator (55 Wh): | 110 Hours |
Circular Saw (13 Amp) (1500 Wh): | 4 Hours |
Yeti Integration Kit | Manufacturer Name: | Goal Zero |
Made: | USA |
Dimensions: | 7.5 x 11.25 x 4.5 in |
Weight: | 9.5 lbs. |
Warranty: | 1 Year Warranty |
Specifications | Voltage: | 120 Single-Phase |
Frequency: | 60 Hertz |
Rated Watts: | 1875 Watts |
Rated Amps: | 15 @ 120 Volts (Single Phase) Amps |
Enclosure: | NEMA 1R |
Conduit Length: | 18 |
Number of Circuit Breakers: | 4 |
Max Generator Input: | 15 Amps |
Maximum Wattage: | 1875 Watts |
UL Listed: | YES |
Transfer Switch Circuits | Circuits: | 4 Circuits: 15A 120V |
Circuit Breaker Protection: | 12V, up to 10A (120W max) |
Yeti Tank Expansion Battery | Manufacturer Name: | Goal Zero |
Chainable: | Yes |
Dimensions: | 15.5" x 7.5" x 10.5" in (39.37 x 19.05 x 26.67 cm) |
Weight: | 77.1 lbs. |
Cell Chemistry: | AGM Lead Acid |
Pack Capacity: | 1200Wh (12V, 100Ah) |
Warranty: | 1 Year Manufacturer Warranty |
Charge Time: | Wall Charger (72W): 18 Hrs
|
Max Input from Yeti Tank Charge Time: | Goal Zero Yeti 1000: 454-605W Goal Zero Yeti 1400: 454-750W Goal Zero Yeti 3000: 750W |
Expansion port male connector (input/output): | 100A Max |
Expansion port female connector (input/output) | 100A Max |
Yeti Link Expansion Module | Manufacturer Name: | Goal Zero |
Chainable: | No |
Dimensions: | 10.25" x 3.3" x 1.5" in (26 x 8.4x 3.8 cm) |
Weight: | 1.5 lbs. |
Input Port: | 8mm Charging port: 14 - 22V (Do not exceed 150W) |
Output Port: | Expansion Module Connector 75A charge controller |
